ELK 9244 4-Module Sensitive Relay, DPDT, 12/24VDC

Small signal. Big switching.

A 4-module DPDT relay that triggers at just 1.2mA and switches dry contacts for general-purpose and high-current loads on 12 or 24VDC.

$154.08
In stock
See details
Fast shippingELKSecure checkout
ELK 9244 4-Module Sensitive Relay DPDT
Triggers at 1.2mAPositive or negative input
DPDT (Form "C") dry contact12 or 24VDC operation

A weak signal should still switch a heavy load.

Many control signals carry very little current. A sensitive relay lets that low-level trigger switch a separate circuit, including high-current loads.

✕
Without itWithout it, a low-current trigger may not reliably operate the device you need it to control.
✓
With the 9244With it, a 1.2mA input drives isolated DPDT dry contacts, with an LED showing the state of each module.
What you get

Four relays, one snap-track board

Each module is built for dependable switching and simple installation.

Sensitive 1.2mA trigger

Operates at an exceptionally low 1.2mA, so small control signals can switch the relay.

ELK 9244 4-Module Sensitive Relay, DPDT, 12/24VDC
1.2mA

Trigger current

The level at which each module triggers.

Positive or negative input

Compatible with both positive and negative input signals, which gives flexibility when wiring to different sources.

Heavy-duty contacts

Each module features heavy-duty contact ratings for general-purpose applications and high-current loads.

LED status per module

An onboard LED status indicator on each module shows at a glance when the relay is active.

The brand

ELK

55 ELK products at Raztechs.

Shop ELK
  • Fast shippingUS and Canada
  • 30-day returnsOn eligible items
  • Quotes & sourcingJust ask
Details

Everything you need to know.

BrandELK
Model9244
Type4-Module Sensitive Relay
Contact formDPDT (Form "C") dry contact
Operating voltage12 or 24VDC
Trigger current1.2mA
Input signalPositive or negative
Modules4
Status indicatorOnboard LED on each module
MountingStandard 2.75" snap track
Description

ELK 9244 4-Module Sensitive Relay, DPDT, 12/24VDC

The 9244 4-Module Sensitive Relay delivers reliable DPDT (Form "C") dry contact switching for general-purpose applications and high-current loads. Operating on 12 or 24VDC, it triggers at an exceptionally low 1.2mA—compatible with both positive and negative input signals. Each module features heavy-duty contact ratings, an onboard LED status indicator, and mounts directly into standard 2.75″ snap track systems. Double-sided foam mounting tape is included for flexible installation options. Built for durability with a lifetime limited warranty, this relay module is packaged in a reusable storage box and ready for immediate deployment in industrial control, automation, and switching applications.
Good to know: The relay mounts in standard 2.75" snap track, and double-sided foam mounting tape is included if you prefer another mounting method.

Need help with compatibility?

Looking for a manufacturer part number, compatible replacement, or quantity order? Contact Raztechs for sourcing and quote support.

Request a quote
ELK 9244 4-Module Sensitive Relay, DPDT, 12/24VDC
In the box

ELK 9244, ready to order.

  • Double-sided foam mounting tape
