Winland TA-40 Mechanical Temperature Alert Freezing Protection Sensor

Freeze warning, no power needed.

A small mechanical sensor that closes a dry contact above 39.5 F (4.2 C) and opens it as temperature falls, so your hardwire or wireless alarm system can warn you of freezing.

$72.00
In stock
See details
Fast shippingWinland ElectronicsSecure checkout
Winland Electronics TA40 Temperature Alert
Pipes getting coldContact opens below 39.5 F
No power requiredMechanical operation

An unattended building can freeze without anyone knowing.

Homes, mountain cabins and other unattended buildings are at risk when the temperature falls. The TA-40 gives your existing alarm system a simple, low cost way to be told.

✕
Without itWithout it, a cold snap can go unnoticed until the damage is done.
✓
With the TA-40With it, your hardwire or wireless alarm system is triggered when the temperature falls below 39 F (4 C).
What you get

Simple freeze protection

The TA-40 is a compact, mechanical sensor built to work with the alarm system you already have.

No power required

It operates without power and connects to most hardwire or wireless alarm systems.

Winland TA-40 Mechanical Temperature Alert Freezing Protection Sensor
39.5 F

Fixed N.C. set point (4.2 C)

The contact is normally closed at temperatures above this fixed setting.

Normally closed dry contact

The N.C. contact stays closed above 39.5 F (4.2 C) and is not for high voltage use.

Unobtrusive size

At 2.5" x 0.8" x 0.55" (6.4cm x 2.0cm x 1.4cm) and 3.0oz (85.0g), it stays out of sight.

Easy surface mounting

Two screw holes let you mount it directly onto a surface.

The brand

Winland Electronics

26 Winland Electronics products at Raztechs.

Shop Winland Electronics
  • Fast shippingUS and Canada
  • 30-day returnsOn eligible items
  • Quotes & sourcingJust ask
Details

Everything you need to know.

BrandWinland Electronics
ModelTA-40
Product TypeMechanical Temperature Alert
Set PointFixed, N.C. >39.5 F (>4.2 C)
Temperature Accuracy±5.4 F (±3.0 C)
Contact TypeN.C. dry contact
Mount TypeSurface Mount
Dimensions2.5" x 0.8" x 0.55" (6.4cm x 2.0cm x 1.4cm)
Weight3.0oz (85.0g)
ColorWhite
Environmental CertificationRoHS
Country of OriginUS
Description

Winland TA-40 Mechanical Temperature Alert Freezing Protection Sensor

The Winland TA-40 is a mechanical temperature alert sensor designed to monitor freezing conditions and protect your property from cold-weather damage. This reliable device triggers an audible alarm when temperatures drop to 40°F or below, alerting you to potential freeze risks before costly damage occurs.

Ideal for mobile homes, RVs, vacation properties, and outdoor installations, the TA-40 requires no batteries or electricity—the mechanical design operates independently with simple, dependable operation. Install it in pipes, refrigerators, crawl spaces, or any area vulnerable to freezing temperatures.

Perfect for seasonal closures, remote properties, or backup protection on existing heating systems. Durable construction ensures years of trouble-free performance in harsh environments.
Good to know: Do not place the TA-40 in cooler or freezer environments. It is for non-condensing environments only.

Need help with compatibility?

Looking for a manufacturer part number, compatible replacement, or quantity order? Contact Raztechs for sourcing and quote support.

Request a quote
Winland TA-40 Mechanical Temperature Alert Freezing Protection Sensor
At a glance

Winland Electronics TA-40, ready to order.

  • Product Type: Mechanical Temperature Alert
  • Set Point: Fixed, N.C. >39.5 F (>4.2 C)
  • Temperature Accuracy: ±5.4 F (±3.0 C)
  • Contact Type: N.C. dry contact
$72.00TA-40
