DITEK DTK-2MHLP24F Data and Signaling Circuit Surge Protection Module for 24V Circuits

Clear the surge off your loop.

A 24V surge protection module for signaling and data circuits. It protects two 24V pairs per module and removes the load instead of shorting to ground.

$192.06
In stock
See details
Fast shippingDITEKSecure checkout
DITEK DTK-2MHLP24F 24V Surge Protection Module
Surge hits the loopLoad removed, not shorted
Two 24V pairs per moduleField replaceable edge card

Alarm and signaling loops need their own surge protection.

Fire alarm, burglar alarm and current loop circuits run on low-voltage wiring that connects to your equipment. A surge protector on those circuits is part of a complete installation.

✕
Without itWithout it, the signaling circuits that reach your alarm panel have no dedicated surge protection.
✓
With the DTK-2MHLP24FWith it, two 24V pairs per module are protected by a multi-stage SAD hybrid design that removes the load instead of shorting to ground.
What you get

Built for fast, flexible installs

The modular design keeps installation simple and scales from one module to a larger base.

Load removal design

This series was designed to remove load instead of shorting to ground.

DITEK DTK-2MHLP24F Data and Signaling Circuit Surge Protection Module for 24V Circuits
24V

Circuits protected

Protects two 24V pairs per module.

Multi-stage SAD hybrid

Multi-stage SAD technology in a hybrid design provides the best possible protection.

Field replaceable modules

A modular edge card connection with a single point ground allows fast installation and saves time.

Multi-base mounting

A hard-wired multi-base mounting system protects up to ten pairs with a common ground.

The brand

DITEK

45 DITEK products at Raztechs.

Shop DITEK
  • Fast shippingUS and Canada
  • 30-day returnsOn eligible items
  • Quotes & sourcingJust ask
Details

Everything you need to know.

BrandDITEK
ModelDTK-2MHLP24F
CompatibilityFire Alarm Panel SLC, PIV and IDC Circuits; Burglar Alarm Panel IDC Circuits; 4-20mA Current Loops
Input Voltage24V DC
Product SeriesDTK-2MHLPF
MaterialABS Plastic
Height1.9"
Width1.4"
Depth2.1"
weight1.20oz
Environmental CertificationRoHS
Country of OriginUS
Description

DITEK DTK-2MHLP24F Data and Signaling Circuit Surge Protection Module for 24V Circuits

The DTK-2MHLP24F surge protection module safeguards two 24V circuits with advanced load removal technology. Featuring multi-stage, SAD hybrid design, this field-replaceable module delivers superior protection across voice and data applications. Six available voltage levels accommodate diverse system requirements. The modular edge card design enables quick installation with a single point ground connection. Hard-wired multi-base mounting supports up to ten pairs on a common ground, maximizing efficiency in larger installations. Suitable for both AC and DC circuits, this module combines reliability with flexible deployment options for professional networking and signaling environments.
Good to know: Intended for circuits that operate at less than 1 Amp. Six voltage levels are available across the series, and base part numbers for multi-base mounting are listed separately.

Need help with compatibility?

Looking for a manufacturer part number, compatible replacement, or quantity order? Contact Raztechs for sourcing and quote support.

Request a quote
DITEK DTK-2MHLP24F Data and Signaling Circuit Surge Protection Module for 24V Circuits
At a glance

DITEK DTK-2MHLP24F, ready to order.

  • Compatibility: Fire Alarm Panel SLC, PIV and IDC Circuits; Burglar Alarm Panel IDC Circuits; 4-20mA Current Loops
  • Input Voltage: 24V DC
  • Product Series: DTK-2MHLPF
  • Material: ABS Plastic
$192.06DTK-2MHLP24F
